Project Title : Yadegar-e-Emam Highway (Lot 3)
|
|
Location : Iran - Tehran |
Status : Completed - Road |
Start Date :
Contract No.1 2003 Contract No.2 2008 |
End Date :
Contract No.1 2008 Contract No.2 2010 |
Technical Specifications : Total length of project contains major axis, minor axis, ramps and loops: 13,335 m Width of highway: 30 m 6 bridges with different length & bays: -One double span bridge, each span 16.5 m long -One underpass bridge with a 12 meter span & 35 m width -Box culvert bridge with a 9 meter span and 180 meter length -One underpass with a 12 meter span and 42 meter length -The great bridge over Darake river with a 30 meter span and 160 meter length in two separate 15 meter bonds -The great bridges over Chamran highway as flyover junction with six 26 meter spans and four spans with average length of 20 meter totally 226 meter length in two separate bonds of 15 meter Total length of retaining walls with 1 to 15 meters high: 3,900 m Earth works: 1,200,000 m3 Steel works: 5,100 ton Heavy steel works: 2,200 ton Formworks: 150,000 m2 Concrete: 90,000 m3 Masonry: 66,000m3 Sub base: 13,900 m3 Base: 12,700 m3 Asphalt: 46,000 ton |
Employer Tehran Municipality Engineer Passillo Consulting Engineers Total Updated Contract Prices 79,000,000 USD
|
Description : |
|
